Choline Chloride Plant - 40 TPD
Stock # 239
Capacity 40 TPD
Products Choline Chloride
Sold

Overview

Used 40 TPD Choline Chloride Plant. This plant produced high purity liquid choline chloride (vitamin B4) which is primarily used as a feed additive. CC liquid is produced by the reaction of trimethylamine (TMA) with hydrochloric acid (HCl) and ethylene oxide (EO) in a continuous reactor. The yield on key raw materials: HCl and EO > 99%, TMA 98% with 2% recycled. The process can be highly automated and requires a minimum of personnel. TMA-HCl is produced by the reaction of TMA and HCl in a reactor. See plant # 240 for details of TMA-HCl production unit.

Major Equipment

This complete plant includes TMA-HCl and CC liquid production units. The equipment has been dismantled, cleaned and stored in separate container. Major equipment:
Titanium lining reactor
Steel evaporator
Steel scrubber
Ethylene oxide scrubber
Ethylene oxide reactor
Pumps, valves, flow and pH instruments
Share
SPECIFICATIONS RESOURCES
Year Build
1968
Year Shut
2006
Capacity
40 TPD
