41000 KW General Electric PG6541B Gas Turbine Generator

41000 KW General Electric PG6541B Gas Turbine Generator
Other Views - click image for larger view
41000 KW General Electric PG6541B Gas Turbine Generator 41000 KW General Electric PG6541B Gas Turbine Generator
STOCK# 18301
Capacity 41000 KW
Description

Used General Electric Frame 6B gas turbine generator set consist of following: GE model 6541B gas turbine, Duel fuel base rated 41,590 KW, water injected combustion; With inlet air cooled, heat rate at Iso 10,860 btu/kwh, Serial number 295591, 5100 rpm; Diesel Black start engine; Accessory gear box with atomizing air compressor, Serial number 140643; Philadelphia Load gear HP rating 68391 , Serial number 139816, Model S664A model 224H0L-A, Input 5094 rpm output 3600 rpm; Resorcon turbine inlet air cooling system; Side exhaust to HRSG; Water injection pump and system for Nox control; Natural gas compressor and gas train; Liquid fuel pump and supply system; Ge TEWAC generator rated 46,500 kva, 13800 v, 3 phase, 60 hz, pf: 0.9, Serial number 33X415, 1945 amps, 125 v exciter volts , field amps 778. 3600 rpm; Mark IV control system; GAC with GE VB1 3000 amps circuit breaker; Enclosure indoor housed History: Unit installed 1990 and it was in hot standby many years, shutdown 2020. Total hours 86,704.60 / Total starts 2,466. Last overhaul 2014 - approx. 2000 hours since last overhaul. Still installed in place.

Specifications
Manufacturer General Electric
Model# PG6541B
Material NA
Capacity 41000 KW
